DPC Front Monitor Temperature Control Device

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The DPCfront Monitor temperature control device is designed as a control device with special functions: heating current monitoring, external setpoint switching and communication through RS 485. It works in the factory setting as a PID control device

DPC Front Monitor Temperature Control Device

•  Process-value feedback by 4 to 20 mA analog output
• Logic output for SSR
• Universal measuring input
• Modbus RTU
• Very good measuring accuracy

The DPCfront Monitor temperature control device is designed as a control device with special functions: heating current monitoring, external setpoint switching and communication through RS 485. It works in the factory setting as a PID control device with a logic output and a relay output. As an alternative, the same device can also be used as a ON/OFF control device. The device is used to regulate a logic output for solid state relays. The relay output is used for alarm signalling. In addition a digital input can be used to choose between different setpoints. The high and low alarm function, sensor monitoring, heating circuit monitoring and heating current monitoring offer additional safety for temperature regulation. When using the device with the factory setting, a simple setup is used for putting into operation for the first time. For example the setpoint, analog output limits, heating currents, low alarm, and if desired, the high alarm must be set.

Application Areas:

• Industrial process monitoring
• Laboratory environments
• Cold storage rooms
• Pharmaceutical and food storage
• Data centers
• Greenhouse and agricultural applications
• HVAC system monitoring
• Furnace and drying system monitoring
• Extruder Heating monitoring
• Hot press applications monitoring.

ELAK-Ex-4.21 Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

The ELAK-Ex-4.21 junction box in conventional design is suitable for use in potentially explosive atmospheres in accordance with Ex directives.

ELAK-Ex-4.21

Suitable connection:

• 1 Trace heater ELK-MI /-MI-Twin
• 1 Power cable

122 x 120 x 90 mm, polyester, IP66, 1 heating cable, 1 supply line. The junction box ELAK-Ex-4.21 in conventional design is suitable for use in potentially explosive atmosphere in accordance with Ex-guidelines. It is easy to install and promises easy maintenance. The junction box can be wall-mounted and can also be installed on pipes with a mounting bracket or variable mounting bracket.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces
• Heat treatment plants
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)

ELAK-Ex-4.22 Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

The ELAK-Ex-4.22 junction box in conventional design is suitable for use in potentially explosive atmospheres in accordance with Ex directives.

ELAK-Ex-4.22

Suitable connection:

• 2 Trace heater ELK-MI /-MI-Twin
• 1 Power cable

The junction box ELAK-Ex-4.22 in conventional design is suitable for use in potentially explosive atmosphere in accordance with Ex-guidelines. It is easy to install and promises easy maintenance. The junction box can be wall-mounted and can also be installed on pipes with a mounting bracket or variable mounting bracket.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces
• Heat treatment plants
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)
• Cable junction boxes (in hazardous areas)
• Heating cable connections (in hazardous areas)
• Sensor connections (in hazardous areas)

DPC III Standard Temperature Control Device

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The DPC III Standard Temperature Controller is a basic controller, which in the factory setting can be used as a two-position controller with two-relay outputs for control and alarm signalling for standard applications.

DPC III Standard Temperature Control Device

• Pre-defined parameters for two-position controller
• Easy setup, fast commissioning
• Load relay/alarm relay/logic output for semi-conductor relay

The DPC III Standard Temperature Controller is a basic controller, which in the factory setting can be used as a two-position controller with two-relay outputs for control and alarm signalling for standard applications. Due to the default basic setting only the setpoint and the alarm level(s) need to be set. The easy start-up function makes this extremely user-friendly. As an alternative, the same device can also be used as a controller with PID control characteristics and an external semi-conductor relay.

Application Areas:

• Industrial furnaces and dryers
• Plastic processing machines (extruders, injection machines)
• Food processing equipment
• Chemical processes
• Laboratory equipment
• Power plants
• HVAC systems
• Extruder Heating
• Hot press applications
• Heat treatment plants
• Packaging machines
• Cooling systems
• Ceramic kilns
• Incubators
• Medical equipment
• Simple heating and cooling applications
• Paint ovens
• Textile machines

DPC III Monitor Temperature Control Device

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The DPC III Monitor Temperature Controller is a basic controller which in the factory setting can be used as a ON/OFF controller with two relay outputs for control and alarm signalling for standard applications.

DPC III Monitor Temperature Control Device

• Pre-defined parameters for two-position controller
• Easy setup, fast commissioning
• Load relay/alarm relay/logic output for semi-conductor relay
• RS 485 Modbus

The DPC III Monitor Temperature Controller is a basic controller which in the factory setting can be used as a ON/OFF controller with two relay outputs for control and alarm signalling for standard applications. Due to the default basic setting only the setpoint and the alarm level(s) need to be set. The easy start-up function makes this extremely user-friendly. As an alternative, the same device can also be used as a controller with PID control characteristics and an external semi-conductor relay. The monitor version is equipped with an RS485 interface and MODBUS protocol.

Application Areas:

• Industrial process monitoring and control
• Laboratory environments
• Cold storage and food storage
• Pharmaceutical and medical supply storage
• Data centers and server rooms
• Greenhouse and agricultural applications
• HVAC systems monitoring
• Furnace and drying systems monitoring
• Extruder Heating monitoring
• Hot press applications monitoring
• Climate control systems
• Environmental monitoring

Pt100 M Resistance Thermometer

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

It is perfectly suited for application areas that require a high degree of flexibility and interchangeability (e.g. chemical and power plants) and is specially designed for use in potentially explosive areas.

Pt100 M Resistance Thermometer

• Fast response time
• Flexible connection cable for easy installation
• Compact dimensions, compact design

This Pt100 Ex sheathed resistance thermometer has been particularly designed for use in potentially explosive areas. As it meets the requirements of the Ex m type of protection, intrinsically safe circuits can be dispensed with. Thanks to the pliable part of the resistance thermometer, the device is excellently suitable for application areas requiring a high degree of flexibility and replaceability (e.g. chemical and power plants)

Structure The resistance thermometer is made of a 3 mm mineral insulated cable with different lengths. This light mineral insulated cable is filled with magnesium oxide. The pliable part of the resistance thermometer starts after 50 mm. Via a transition gland, the connection to a flexible supply cable is created.

Function Metals increase the electrical resistance with rising temperatures. The platinum element of the resistance thermometer has a resistance of 100 Ω at 0 °C. This characteristic is used for this type of resistance thermometers to get an image of the temperature. The resistance changes of the Pt100 Ex are converted into a temperature value and displayed by a control unit.

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• HVAC systems
• Laboratories
• Plastic processing machines
• Metal processing
• Automotive industry
• Greenhouse and agricultural applications
• Extruder Heating
• Hot press applications.

DTL III Ex Digital Safety Temperature Limiter

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The heating or heating circuits can be installed in both environmentally protected and hazardous areas. Thanks to the integrated power supply unit with wide voltage range, the devices can be used almost anywhere in the world.

DTL III Ex Digital Safety Temperature Limiter

• ATEX approved limite
• Optimised for trace heating applications (with service contact
• In conjunction with Pt100 Ex, it can be used for monitoring temperature in explosionprotected heating circuit

The DTL III Ex digital temperature limiter, which is adapted to (trace) heating applications, serves to monitor heating and heating circuits. The device is installed in the non-hazardous area. The heating or heating circuits can be installed both in media-protected and also in hazardous areas. Thanks to their integrated power supply unit with wide-range voltage, the devices can be used almost everywhere in the world

Function If the temperature at the Pt100 exceeds the set limit value, the DTL III Ex permanently interrupts the normally closed 16 A switch contact. This situation is detected by a volt-free alarm contact (change-over contact) and passes on the signal to the control panel. After a temperature drop of 5 K below the limit set point, or after a fault has been remedied, the limiter can be re-activated by means of a re-set button on the device itself or via a remote re-set control. The DTL will also interrupt the switch contact in the event of a sensor open or short circuit. Process reliability is increased by additional monitoring functions such as supply voltage monitoring, pre-alarm, measuring circuit monitoring for sensor break, interruption and short-circuit as well as undershooting/overshooting of the measuring range. A multi-stage password management is available for effective parameter protection. When doing service work on the heating circuit, the load output can be turned off by means of a digital input and the temperature alarms can be disabled. Using the programming interface, the device parameters can be read out with a programming key and transmitted to other devices.

Structure The DTL III Ex is integrated in a latch-on enclosure for TS 35 mounting rails. The alarm relay is produced as a change-over contact and the limit relay as a normally open contact. The voltage is supplied to the control device through an integrated power supply unit with wide-range voltage. The electrical connection is established with terminal screws operating on the screw cage clamp principle, ensuring a safe connection that is gentle on conductors.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces (in hazardous areas)
• Heat treatment plants (in hazardous areas)
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)
• Heating cable applications (in hazardous areas)
• Sensor connections (in hazardous areas)

DPC CodeKey Programming Key For DPC III And DPC

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The DPC CodeKey makes it easier to set parameters for the DPC device family. Once a reference device has been successfully programmed, the operating parameters are available in a device-memory read-out.

DPC CodeKey Programming Key For DPC III And DPC

• Easy programming of DPC devices
• Operation independent of voltage supply
• SMART converter function USB/RS485

The DPC CodeKey makes it easier to set parameters for the DPC device family. Once a reference device has been successfully programmed, the operating parameters are available in a device-memory read-out. The parameters filed in the CodeKey can be copied into other devices any number of times. This reduces the programming work to a minimum. In addition, the CodeKey can be used as an interface converter between the USB and RS485.

Mode of Operation A DIP switch can be used to select the device function required. The DPCfront and DPC III have at the side or under the display cover a 5-pin interface into which the CodeKey is inserted. The transmission is started at the press of a button. Once done, a status LED flashes. Voltage is supplied to the CodeKey through the interface.

Application Areas:

• Industrial furnaces and drying systems
• Plastic processing machines
• Food processing equipment
• Chemical processes
• Laboratory equipment
• Heat treatment plants
• Power plants
• HVAC systems
• Extruder Heating
• Hot press applications
• Rapid configuration of multiple DPC control devices
• Mass production and calibration in factory environments
• Maintenance and repair of DPC control devices
• Secure storage of programming parameters.

ELAK-Ex-2.00 Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

The junction box ELAK-Ex-2.00 in conventional design is suitable for use in potentially explosive atmosphere in accordance with Ex-guidelines.

ELAK-Ex-2.00

Suitable connection:

• 1 Trace heater ELSR, ELK-AG, ELK-MI or ELK-MI Twin
• 1 Power cable

The junction box ELAK-Ex-2.00 in conventional design is suitable for use in potentially explosive atmosphere in accordance with Ex-guidelines. It is easy to install and promises easy maintenance. The junction box can be wall-mounted and can also be installed on pipes with a mounting bracket or variable mounting bracket.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces
• Heat treatment plants
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)
• Cable junction boxes (in hazardous areas)
• Heating cable connections (in hazardous areas)
• Sensor connections (in hazardous areas)
• Lighting systems (in hazardous areas)
• Distribution boxes (in hazardous areas)

ELVB-MI-VA-S Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

Factory assembly, laser-welded, single wire

ELVB-MI-VA-S

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• Metal processing
• Automotive industry
• Aerospace industry
• Nuclear power plants
• Extruder Heating
• Hot press applications
• High temperature pipelines
• Tank heating

ELVB-MI-VA-T Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

Factory assembly, laser-welded, two wire

ELVB-MI-VA-T

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• Metal processing
• Automotive industry
• Aerospace industry
• Nuclear power plants
• Extruder Heating
• Hot press applications
• High temperature pipelines
• Tank heating
• Steam lines
• Heat treatment furnaces
• High temperature reactors.

ELVB-MI-AY825- S Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

Factory assembly, laser-welded, single wire

ELVB-MI-AY825- S

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• Metal processing
• Automotive industry
• Aerospace industry
• Nuclear power plants
• Extruder Heating
• Hot press applications
• High temperature pipelines
• Tank heating
• Steam lines
• Heat treatment furnaces
• High temperature reactors
• High temperature valves
• High temperature sensors

ELVB-MI-AY825- T Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

Factory assembly, laser-welded, two wire

ELVB-MI-AY825- T

Features:

• Mineral insulated heating cable
• High temperature resistance
• Durable and reliable construction
• Suitable for various industrial environments
• Customizable for specific applications
• High thermal efficiency
• Fast response time

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• Metal processing
• Automotive industry
• Aerospace industry
• Nuclear power plants
• Extruder Heating
• Hot press applications
• High temperature pipelines
• Tank heating
• Steam lines
• Heat treatment furnaces
• High temperature reactors
• High temperature valves
• High temperature sensors
• Heating applications requiring fast response

ELAK-6-SP Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

The junction box ELAK-6-SP is fast and easy to install and maintain thanks to its conventional design. The design allows for different configurations.

ELAK-6-SP

The junction box ELAK-6-SP is fast and easy to install and maintain thanks to its conventional design. The design allows for different configurations. The junction box ELAK-6-SP is suitable for wall mounting but can also be installed on pipes with the aid of a mounting fixture.

Features:

• Connection box designed for industrial applications
• High temperature resistance
• Durable and reliable construction
• Easy installation
• Multiple connection options for various cable entries

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• Metal processing
• Automotive industry
• Aerospace industry
• Nuclear power plants
• Extruder Heating
• Hot press applications
• High temperature pipelines
• Tank heating
• Steam lines
• Heat treatment furnaces
• High temperature reactors
• Cable junction boxes
• Heating cable connections
• Sensor connections

ELAK-3-SP Ex Proof Connection box

Brand: ELTHERM

Category: EX PROOF HEAT TRACING EQUIPMENT

The junction box ELAK-3-SP is fast and easy to install and maintain thanks to its conventional design. The design allows for different configurations.

ELAK-3-SP

The junction box ELAK-3-SP is fast and easy to install and maintain thanks to its conventional design. The design allows for different configurations. The junction box ELAK-3-SP is suitable for wall mounting but can also be installed on pipes with the aid of a mounting fixture.

Features:

• Connection box designed for industrial applications
• High temperature resistance
• Durable and reliable construction
• Easy installation
• Multiple connection options for various cable entries
• Compact design

Application Areas:

• Industrial furnaces and dryers
• Chemical processes
• Food processing
• Pharmaceutical production
• Power plants
• Metal processing
• Automotive industry
• Aerospace industry
• Nuclear power plants
• Extruder Heating
• Hot press applications
• High temperature pipelines
• Tank heating
• Steam lines
• Heat treatment furnaces
• High temperature reactors
• Cable junction boxes
• Heating cable connections
• Sensor connections
• Small-sized systems and equipment
• Space-constrained applications

GW32 Gateway

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The GW32 gateway connects the MC32 modules, which operate independently of each other, into a complete system. It serves as an interface between the controller hardware and the MPCnet ProcessDesigner software.

GW32 Gateway

The GW32 gateway connects the MC32 modules, which operate independently of each other, into a complete system. It serves as an interface between the controller hardware and the MPCnet ProcessDesigner software. The PA00 touch panel also accesses the control system’s parameters through the gateway. The physical connection is established by means of the RS232 interface. In conjunction with the PA00 touch panel, the GW32 also establishes communication between a higher-ranking control system and the MPCnet. The PA00 touch panel serves as the interface here. See the system description for the Installation Instructions.

Features:

• Designed for Industrial IoT (Internet of Things) applications.
• Data collection and transmission from various sensors and devices.
• Remote monitoring and control capability.
• Secure data communication.
• Easy installation and configuration.

Application Areas:

• Industrial automation
• Energy management
• Smart city applications
• Agriculture and environmental monitoring
• Logistics and transportation
• Building automation
• Remote equipment monitoring
• Process monitoring
• Data collection and analysis
• Remote temperature monitoring and control
• Remote humidity monitoring and control
• Remote pressure monitoring and control
• Remote energy consumption monitoring.

MC32 Controller Module

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The MC32 Controller module regulates and monitors up to 32 heating circuits. It flexibly accesses the individual I/O modules by means of the bus system integrated in the DIN rail.

MC32 Controller Module

The MC32 Controller module regulates and monitors up to 32 heating circuits. It flexibly accesses the individual I/O modules by means of the bus system integrated in the DIN rail. By inserting more MC32 modules into the bus, the number of heating circuits to be monitored can be increased at will. Two setpoint values can be assigned to each heating circuit and changed by means of an external switching contact. The MC32 monitors parameters, such as temperature, overheating, load current, residual current, and external status signals such as rccb auxiliary contacts, limiter alarms, manual switches etc. for each of the 32 heating circuits individually. Up to three temperature sensors per circuit are monitored, whereby the controlled variable is fixed in relation to one sensor. The other sensors serve to monitor a high and a low alarm value. Individual upper and lower limits can be assigned to each monitored value and individual alarms emitted by means of the MPCnet control system’s digital outputs. In addition, all individual alarms can be emitted through the MC32 module’s group alarm contact to an indicator light or suchlike. The bus status signals and alarms are also indicated by means of LEDs. Connecting the GW32 gateway and PA00 touch-panel allows a transfer not only of the setpoint and actual values but also of all alarms into a higher ranking control. All of the control system’s parameters and alarms can be altered or acknowledged from the control centre. See system description for the Installation Instructions.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Robotics applications
• Motion control
• HVAC systems
• Energy management
• Data acquisition and analysis
• Remote monitoring and control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control.

Remote I O Module 8TI 16TI

Brand: BARTEC

Category: INDUSTRIAL PRODUCTS

The 8TI and 16TI temperature registering modules are suitable for the direct connection of 3-wire Pt100 temperature sensors. They are operated and supplied by means of the MC32 controller.

Remote I O Module 8TI 16TI

The 8TI and 16TI temperature registering modules are suitable for the direct connection of 3-wire Pt100 temperature sensors. They are operated and supplied by means of the MC32 controller. The internal, galvanically isolated bus connection is established by simply joining the modules. The modules feature open-circuit/short-circuit detection. LEDs display the bus status messages and fault signals. See system description for the Installation Instructions.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Remote monitoring and control
• Data acquisition and analysis
• Energy management
• HVAC systems
• Robotics applications
• Motion control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Conveyor systems control
• Packaging machines control.

Remote I/O Module 8TI 16TI

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The 8DO and 16DO output modules are suitable for indirectly switching heating cables via a power contactor. Additionally, individually adjustable alarms can be output via digital outputs.

Remote 8DO And 16DO I/O  Modules

The 8TI and 16TI temperature registering modules are suitable for the direct connection of 3-wire Pt100 temperature sensors. They are operated and supplied by means of the MC32 controller. The internal, galvanically isolated bus connection is established by simply joining the modules. The modules feature open-circuit/short-circuit detection. LEDs display the bus status messages and fault signals. See system description for the Installation Instructions.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Remote monitoring and control
• Data acquisition and analysis
• Energy management
• HVAC systems
• Robotics applications
• Motion control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Conveyor systems control
• Packaging machines control
• Lighting systems control
• Motor control
• Valve control.

Remote I/O Module 8D I16D

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The 8DI and 16DI digital input modules register and monitor diverse status signals. The inputs are floating, and this means that non-floating contacts are required for transmitting signals.

Remote I O Module 8D I16D

The 8DI and 16DI digital input modules register and monitor diverse status signals. The inputs are floating, and this means that non-floating contacts are required for transmitting signals. They are operated and supplied through the MC32 controller. The internal, galvanically isolated bus connection is established by simply joining the modules together. LEDs display the bus status messages and other status messages per channel. See the system description for the Installation Instructions

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Remote monitoring and control
• Data acquisition and analysis
• Energy management
• HVAC systems
• Robotics applications
• Motion control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Conveyor systems control
• Packaging machines control
• Security systems
• Alarm systems
• Sensor data acquisition.

Remote I/O Module 8CI 16CI

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The 8CI and 16CI current measuring modules register load and residual currents in conjunction with the LoaC and LeaC measuring transducers. Up to three phases and the total current can be monitored for each heating circuit.

Remote I O Module 8CI 16CI

The 8CI and 16CI current measuring modules register load and residual currents in conjunction with the LoaC and LeaC measuring transducers. Up to three phases and the total current can be monitored for each heating circuit. The individual inputs are assigned and configured either by means of the MPCnet ProcessDesigner software or by the touch panel. The modules are operated and supplied through the MC32 controller. The internal, galvanically isolated bus connection is established by simply joining the modules together. See the system description for the Installation Instructions.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Remote monitoring and control
• Data acquisition and analysis
• Energy management
• Motor control
• Pump control
• Current monitoring
• Power monitoring
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Conveyor systems control
• Packaging machines control
• Welding machines control
• Electrolysis applications.

Communication Modules TM04 TS04

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The TR16, TR26 and TR38 power modules are integrated into the MPCnet network architecture by means of the TM04 and TS04 communication modules, whereby up to 4 power modules can be connected to each communication module.

Communication Modules TM04 TS04

The TR16, TR26 and TR38 power modules are integrated into the MPCnet network architecture by means of the TM04 and TS04 communication modules, whereby up to 4 power modules can be connected to each communication module. The communication between the individual power modules and the MC32 controller is established by means of the TM04 master module. By inserting more TS04 communication modules into the bus, the number of connectable power modules can be extended to 32. See system description for the Installation Instructions.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Remote monitoring and control
• Data acquisition and analysis
• Energy management
• HVAC systems
• Robotics applications
• Motion control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Conveyor systems control
• Packaging machines control
• Data acquisition systems
• Network communication
• Industrial networks
• Remote maintenance.

Power Modules TR116 TR316

Brand: BARTEC

Category: INDUSTRIAL PRODUCTS

The TR116 and TR316 power modules combine the functions of all MPCnet I/O modules in one single module. Each module has two Pt100 inputs and digital inputs for monitoring RCCBs and limiters.

Power Modules TR116 TR316

The TR116 and TR316 power modules combine the functions of all MPCnet I/O modules in one single module. Each module has two Pt100 inputs and digital inputs for monitoring RCCBs and limiters. For each heating circuit the heating power can be adjusted steplessly between 10 % and 100 % for up to three phases, whereby the load and total current are monitored. The modules are operated and supplied via the TM04 or TS04 power module controllers. The set point value is determined by the MC32 controller. The internal, galvanically isolated bus connection is established by simply joining the modules together by means of RJ-45 plug connectors.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Motor control
• Heating systems control
• Cooling systems control
• Lighting systems control
• Energy management
• Robotics applications
• Motion control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Welding machines control
• Electrolysis applications.

PA00 HMI Touch Panel

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The HMI touch panel is used as a central operating unit where all parameters for the entire control system can be set and monitored.

PA00 HMI Touch Panel

The HMI touch panel is used as a central operating unit where all parameters for the entire control system can be set and monitored.

Application Areas:

• Industrial automation systems
• Machine control
• Process control
• Remote monitoring and control
• Data acquisition and analysis
• Energy management
• HVAC systems
• Robotics applications
• Motion control
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control
• Conveyor systems control
• Packaging machines control
• Data acquisition systems
• Network communication
• Industrial networks
• Remote maintenance
• Operator panel applications.

MPCnet TL Ex Temperature Limiter

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

The TL Ex safety temperature limiter is a constituent part of the MPCnet system and is used to monitor heatings and heating circuits. The heatings or heating circuits can be installed both in media-protected and also in hazardous (potentially explosive) areas

MPCnet TL Ex Temperature Limiter

• ATEX approval
• Optimised for trace heating applications (with service contact)
• Fault monitoring
• In conjunction with Pt100 Ex, it can be used for monitoring temperature in explosionprotected heating circuifs

The TL Ex safety temperature limiter is a constituent part of the MPCnet system and is used to monitor heatings and heating circuits. The device is for installation in non-hazardous areas. The heatings or heating circuits can be installed both in media-protected and also in hazardous (potentially explosive) areas.

Function If the temperature at the Pt100 sensor exceeds the set limit value, the TL Ex disconnects the load output permanently. At the same time a floating alarm contact is triggered. The alarm contact status is detected and processed by means of the digital inputs in the 8DI and 16DI modules and the digital input in the TR16, TR36 and TR38 power modules in the MPCnet. Once the temperature drops by 2 K below the switch-off point or after a fault has been remedied, the limiter can be reactivated by means of a reset button on the device. The TL Ex can transmit the temperature detected at the measuring input to the MPCnet by means of an integrated sequential system with a signal that is proportional to the actual value measured. This allows the temperature at the limiter to be evaluated in the control system also. The limiter function can be suppressed by a digital input when carrying out servicing work on the heating circuit, e.g. steam cleaning.

Construction The TL Ex is installed in a clip-on enclosure for TS35 mounting rails. The alarm relay and the limit relay are produced as change-over contacts. The DC 24 V voltage is supplied through the use of a top-hat rail on the underside. The electrical connection is established by means of screw-type terminals operating on the screw cage clamp principle, which ensures a reliable connection and is also gentle on conductors.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces (in hazardous areas)
• Heat treatment plants (in hazardous areas)
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)
• Heating cable applications (in hazardous areas)
• Sensor connections (in hazardous areas)
• Hazardous areas requiring remote temperature monitoring and control.

DEC Digital Energy Controller

Brand: BARTEC

Category: INDUSTRIAL CONTROL PRODUCTS

Combined with the DPCFamily, the DTL III Ex and Pt100 Ex, the DEC can also be used to control heating systems in hazardous (potentially explosive) areas

DEC Digital Energy Controller

• AC 230 V control/supply voltage
• Can be snaped on DIN rail
• Switching capacity AC 230 V, 20 A
• Display: supply voltage, heating on

The DEC is an adjustable energy controller. It allows perfect adaption of the power output from 10 % to 100 % in 10 %-steps. Combined with the DPCFamily, the DTL III Ex and Pt100 Ex, the DEC can also be used to control heating systems in hazardous (potentially explosive) areas.

Structure The DEC case can be snapped onto a DIN rail allowing quick and easy installation. The energy controller is energised via 230 V mains supply voltage. The terminals can accommodate conductors with a cross section of up to 2.5 mm². DEC control via AC 230 V. The front fascia of the case provides a 10-step switch for the power adaption from 10 % to 100 %. An LED on the front fascia indicates whether supply voltage is applied to the DEC. A second LED signals an active/non active DEC output

Function The DEC is controlled via a AC 230 V supply periodic group control is activated via a 10-step switch and the output power of the DEC adjusted from 10 % to 100 %.

Application Areas:

• Industrial facilities
• Production lines
• Power plants
• Building automation
• HVAC systems
• Lighting systems
• Cooling systems
• Heating systems
• Motor control
• Pump control
• Compressor control
• Data centers
• Telecommunication facilities
• Renewable energy systems
• Extruder Heating control
• Hot press applications control
• Furnace control
• Drying systems control.

Additional products DPC III, Digital programmable controller, Type 17-8821-4.22/22303.00 DTL III Ex, Digital temperature limiter, Type 17-8865-4.22/22003000 Pt100 Ex, explosion protected, Type 27-71..-13

Pt100 Ex Resistance Thermometer

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The device is perfectly suited for application areas that require a high degree of flexibility and interchangeability (e.g. chemical and power plants) and is specially designed for use in potentially explosive areas.

Pt100 Ex Resistance Thermometer

• Very fast response time
• Compact dimensions, compact design
• Wide temperature range

This Pt100 Ex sheathed resistance thermometer has been particularly designed for use in potentially explosive areas. As it meets the requirements of the Ex m type of protection, intrinsically safe circuits can be dispensed with. Thanks to the pliable part of the resistance thermometer, the device is excellently suitable for application areas requiring a high degree of flexibility and replaceability (e.g. chemical and power plants)

Structure The resistance thermometer is made of a 3 mm mineral insulated cable with different lengths. This light mineral insulated cable is filled with magnesium oxide. The pliable part of the resistance thermometer starts after 50 mm. Via a transition gland, the connection to a flexible supply cable is created.

Function Metals increase the electrical resistance with rising temperatures. The platinum element of the resistance thermometer has a resistance of 100 Ω at 0 °C. This characteristic is used for this type of resistance thermometers to get an image of the temperature. The resistance changes of the Pt100 Ex are converted into a temperature value and displayed by a control unit.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces (in hazardous areas)
• Heat treatment plants (in hazardous areas)
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)
• Heating cable applications (in hazardous areas)
• Sensor connections (in hazardous areas)
• All applications requiring temperature measurement in hazardous areas.

Junction Boxes For Pt100 Ex

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The Pt100 Ex junction boxes allow one or more two-wire or three-wire Pt100 resistance thermometers to be connected to the signal line. The enclosures have the appropriate terminals and the required cable glands.

Junction Boxes For Pt100 Ex

The Pt100 Ex junction boxes allow one or more two-wire or three-wire Pt100 resistance thermometers to be connected to the signal line. The enclosures have the appropriate terminals and the required cable glands. Aluminium junction boxes are available upon request.

Application Areas:

• Oil and gas industry (refineries, platforms)
• Chemical industry (chemical plants)
• Mining
• Paint industry
• Flour and sugar factories
• High temperature furnaces (in hazardous areas)
• Heat treatment plants (in hazardous areas)
• Hazardous material storage
• Extruder Heating (in hazardous areas)
• Hot press applications (in hazardous areas)
• Heating cable applications (in hazardous areas)
• Sensor connections (in hazardous areas)
• All applications requiring Pt100 sensor connections in hazardous areas.
