HEM-PTCuPFA-68990 220 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.

HEM-PTCuPFA-68990 220 °C Series Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial furnaces and dryers
• High-temperature process equipment
• Chemical process lines
• Laboratory equipment
• Automotive industry (engine and exhaust systems)
• Extruder heating
• Hot press applications
• High-temperature valves and pipelines
• Oil industry applications
• Food industry (high-temperature cooking equipment)
• Packaging industry (heat sealing equipment)
• Composite material production
• High-temperature testing and measurement devices

HEM-PTCuPFA-68991 180 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.

HEM-PTCuPFA-68991 180 °C  Series Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial furnaces and dryers (medium temperature applications)
• High-temperature process equipment
• Chemical process lines
• Laboratory equipment
• Automotive industry (engine and exhaust systems)
• Extruder heating
• Hot press applications
• High-temperature valves and pipelines
• Oil industry applications
• Food industry (high-temperature cooking equipment)
• Packaging industry (heat sealing equipment)
• Composite material production
• High-temperature testing and measurement devices
• Defrosting applications
• Cooling systems
• Freeze protection

HEM-PTCuPT-68500 220 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.

HEM-PTCuPT-68500 220 °C  Series Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial furnaces and dryers
• High-temperature process equipment
• Chemical process lines
• Laboratory equipment
• Automotive industry (engine and exhaust systems)
• Extruder heating
• Hot press applications
• High-temperature valves and pipelines
• Oil industry applications
• Food industry (high-temperature cooking equipment)
• Packaging industry (heat sealing equipment)
• Composite material production
• High-temperature testing and measurement devices
• Plastic processing machines
• Heating silicone molds.

HEM-PFACuPFA-68951 220 °C Seri̇es Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.

HEM-PFACuPFA-68951 220 °C  Seri̇es Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial furnaces and dryers
• High-temperature process equipment
• Chemical process lines
• Laboratory equipment
• Automotive industry (engine and exhaust systems)
• Extruder heating
• Hot press applications
• High-temperature valves and pipelines
• Oil industry applications
• Food industry (high-temperature cooking equipment)
• Packaging industry (heat sealing equipment)
• Composite material production
• High-temperature testing and measurement devices
• Cold storage rooms
• Industrial and domestic cooling devices
• Industrial storage tank heating
• Prevention of snow and ice accumulation and freezing in rail transportation systems.

HEM-PFACuPFA-68994 260 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.

HEM-PFACuPFA-68994 260 °C  Series Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial Furnaces and Dryers: Especially applications requiring higher temperatures.
• High-Temperature Process Equipment: Chemical reactors, thermal oxidation systems, etc.
• Chemical Process Lines: Environments with aggressive chemicals.
• Laboratory Equipment: High-temperature test devices, analytical equipment.
• Aerospace Industry: Engine components, exhaust systems, high-temperature sensors.
• Extruder Heating: High-performance plastic extrusion machines.
• Hot Press Applications: Composite material production, lamination processes.
• High-Temperature Valves and Pipelines: Steam lines, thermal oil systems.
• Oil and Gas Industry: Deep well drilling equipment, refinery processes.
• Food Industry: High-temperature cooking and baking equipment.
• Packaging Industry: High-speed heat sealing machines.
• Composite Material Production: Autoclaves, high-temperature curing ovens.
• High-Temperature Testing and Measurement Devices: Thermal shock tests, combustion tests.
• Heating of silicone molds: Molds that must operate at high temperatures.

HEM-GG-60060 400 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in industrial, freezing areas and many other areas.

HEM-GG-60060 - 400 °C High Temperature Resistant Heating Cable

Application Areas:

• Industrial furnaces (very high temperature applications)
• Heat treatment plants
• Glass and ceramics industry
• Metallurgy industry
• High temperature testing equipment
• Power plants (boilers, turbines)
• Aerospace industry (engine tests, high temperature sensors)
• Research and development laboratories
• Metal smelting plants
• Drying ovens
• Extruder Heating
• Hot press applications

HEM-GMG 400 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in industrial, freezing areas and many other areas.

HEM-GMG 400 °C  Series Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial furnaces (very high temperature applications)
• Heat treatment plants
• Glass and ceramics industry
• Metallurgy industry
• High temperature testing equipment
• Power plants (boilers, turbines)
• Aerospace industry (engine tests, high temperature sensors)
• Research and development laboratories
• Metal smelting plants
• Drying ovens
• Extruder Heating
• Hot press applications

HEM-PFACuPFA-68997 260 °C Series Resistance Polymer Insulated Heating Cables

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.

HEM-PFACuPFA-68997 260 °C  Series Resistance Polymer Insulated Heating Cables

Application Areas:

• Industrial Furnaces and Dryers: Especially applications requiring higher temperatures.
• High-Temperature Process Equipment: Chemical reactors, thermal oxidation systems, etc.
• Chemical Process Lines: Environments with aggressive chemicals.
• Laboratory Equipment: High-temperature test devices, analytical equipment.
• Aerospace Industry: Engine components, exhaust systems, high-temperature sensors.
• Extruder Heating: High-performance plastic extrusion machines.
• Hot Press Applications: Composite material production, lamination processes.
• High-Temperature Valves and Pipelines: Steam lines, thermal oil systems.
• Oil and Gas Industry: Deep well drilling equipment, refinery processes.
• Food Industry: High-temperature cooking and baking equipment.
• Packaging Industry: High-speed heat sealing machines.
• Composite Material Production: Autoclaves, high-temperature curing ovens.
• High-Temperature Testing and Measurement Devices: Thermal shock tests, combustion tests.
• Heating of silicone molds: Molds that must operate at high temperatures.
• Cooling systems: Cold storage rooms, industrial coolers.

EMK Heating Circuit Standard Pre Assembled Laser Welded

Brand: HEMSTEDT

Category: HIGH TEMPERATURE SERIES-RESISTANT HEATING CABLES

The “Standard” connection kits for EMK heating cables are available in 5 versions: EMK Standard 300, EMK Standard 400 S, EMK Standard 400 D, EMK Standard 690 and EMK Standard 690 S/D. The necessary junction box must be ordered for

EMK - Standard Pre-Assembled Laser Source Heating Circuit

The “Standard” connection kits for EMK heating cables are available in 5 versions: EMK Standard 300, EMK Standard 400 S, EMK Standard 400 D, EMK Standard 690 and EMK Standard 690 S/D. The necessary junction box must be ordered for each pre-assembled EMK heating circuit depending on the required mains voltage and the type of wiring (single-phase, two-phase, star connection, delta connection)

Application Areas:

• Industrial process heating
• Heating of pipelines and tanks
• Laboratory equipment
• Plastic processing machines
• Food industry (heating equipment)
• Packaging industry (heat sealing equipment)
• Extruder Heating
• Hot press applications
• Defrosting applications
• Cooling systems.

Type ELP-Si up to 200°C Constant Wattage Trace Heater With Resistance Wire

Brand: ELTHERM

Category: CONSTANT WATTAGE HEATER CABLES

It is used in areas such as tanks, pipes, valves, food processing industry, freeze protection and temperature maintenance in pumps, etc.

Type ELP-Si up to 200°C Constant Wattage Trace Heater With Resistance Wire

The installation of this heating cable is highly cost-efficient with any kind of heat tracing application thanks to the single end power input. The heating cable consists of a succession of heating zones (length = contact spacing) and can be cut to length in sections of the contact distance to the required length. When cutting into lengths, the heating circuit is interrupted up to the next contact point and this non-active part can be used as a cold lead. During the design phase, one contact spacing length per planned heating circuit must be calculated additionally.

Advantages:

• Single end connection
• Can be cut off the roll
• Constant power output per meter
• Highly flexible

Applications:

• Vessels, piping, valves
• Food processing industry
• Frost protection and temperature maintenance on pumps, etc.

Type ELP-PFA up to 260°C Constant Wattage Trace Heater With Resistance Wire

Brand: ELTHERM

Category: CONSTANT WATTAGE HEATER CABLES

It is used in containers, pipes, valves, building construction, food processing industry, paper industry.

Type ELP-PFA up to 260°C Constant Wattage Trace Heater With Resistance Wire

These parallel heating cables offer tremendous flexibility in use, as they can easily be cut to the required length off the roll, with the assurance of constant power output. There is no need for a connecting cable, and input can be unilateral. It is quick and easy to assemble; this saves a lot of time, and as a result reduces cost considerably. Since output of up to 60 W/m is possible for lengths laid to piping, ELP parallel heating cables are particularly suitable for piping with high output requirements, such as in industrial process technology. The particularly temperature-resistant outer shell in PFA and the high level of chemical resistance of the PFA ensure a long useful life.

Advantages:

• Single end power input
• Can be cut off the roll
• Constant power output per meter
• Long life cycle
• Laying without exact measuring possible
• High chemical resistance

Applications:

• Vessels, piping, valves
• Building construction
• Food processing industry
• Paper industry

Insulation Entry Kits

Brand: EHT Mühendislik

Category: ACCESSORIES AND INSTALLATION PRODUCTS

It is used in PSB/PSBL, MSB/HSB, HTSB, Pt100 Ex, EKL single/1 x Pt100 M and EKL double/2 x Pt100 M cables.

Insulation Entry Kits

Application Areas:

• Electrical Panels:
  • Insulation and protection at cable entries.
  • Increase the IP protection class of panels.
• Distribution Boxes:
  • Insulation and protection at cable entries.
  • Ensure the sealing of boxes.
• Machines and Equipment:
  • Insulation and protection at cable entries.
  • Increase the safety of machines and equipment.
• Lighting Systems:
  • Insulation and protection at cable entries.
  • Ensure the sealing of lighting fixtures.
• Industrial Automation:
  • Insulation and protection at cable entries.
  • Sensors, actuators and other automation equipment.
• Telecommunications:
  • Insulation and protection at cable entries.
  • Ensure the safety of telecommunications equipment.
• Renewable Energy Systems:
  • Insulation and protection at cable entries.
  • Solar panels and wind turbines.

An insulation entry bush is used to prevent the heating cable being damaged where it passes through the thermal insulation outer cladding. The plate is made of stainless steel.

Adhesive Tapes

Brand: BARTEC

Category: ACCESSORIES AND INSTALLATION PRODUCTS

he aluminium self-adhesive tape is recommended for improving thermal conductivity and is indispensable for heating plastic pipes.

Adhesive Tapes - Adhesive Tapes

The aluminium self-adhesive tape is recommended for improving thermal conductivity and is indispensable for heating plastic pipes. The glass-fibre self-adhesive tape is recommended for attaching heating cables onto stainless steel and smooth surfaces in the high-temperature range.

Application Areas:

Heating Systems:

• Heating plastic pipes (aluminum tape).

• Attaching heating cables to stainless steel and smooth surfaces (glass fiber tape).

• Mounting of heating equipment.

• Thermal insulation applications.

Industrial Applications:

• High-temperature furnaces and equipment.

• Metal processing and welding applications.

• Surfaces requiring heat transfer.

Electrical and Electronics:

• Cable fixing and insulation.

• Mounting electronic components.

• Electrical panels.

Automotive:

• On hot surfaces like exhaust systems.

• Heat insulation and protection.

Construction:

• Ventilation systems.

• Thermal insulation applications.

Heat Trace Insulation Caution Labels

Brand: EHT Mühendislik

Category: HEAT TRACE – HEATER CABLE TYPES

By law, any pipe that is wrapped with heat trace cable and covered in insulation must have a caution label on the outside of the insulation every 10 feet. This is to warn firefighters of an electrical hazard.

Heat Trace Insulation Caution Labels

Application Areas:

Heating Systems:

• Pipeline and tank insulation.

• High temperature equipment insulation.

• Industrial furnaces and dryers.

Industrial Facilities:

• Steam lines and boilers.

• Chemical process lines.

• Power plants.

Commercial Buildings:

• Heating and cooling systems.

• Hot water pipes.

Shipbuilding:

• Steam and exhaust systems.

• Heating and cooling systems.

Oil and Gas Industry:

• Pipeline and tank insulation.

• Refinery equipment.

Mounting Plates And Brackets In Stainless Steel

Brand: EHT Mühendislik

Category: ACCESSORIES AND INSTALLATION PRODUCTS

For securing enclosures and thermostats to pipework and vessels.

Mounting Plates And Brackets In Stainless Steel

Application Areas:

• Industrial Equipment Mounting:
  • Machine and equipment fixing
  • Conveyor systems
  • Process equipment.
• Electrical and Electronics:
  • Electrical panels and distribution boxes
  • Sensor and actuator mounting
  • Cable management systems.
• Lighting Systems:
  • Lighting fixture mounting
  • Outdoor lighting systems.
• Telecommunications:
  • Telecommunications equipment mounting
  • Antenna mounting.
• Renewable Energy Systems:
  • Solar panel mounting
  • Wind turbine equipment.
• High Temperature Applications:
  • Furnace and dryer mounting
  • Heating systems.
• Chemical Process Equipment:
  • Chemical reactors
  • Pipelines.
• Maritime Applications:
  • Ship equipment mounting
  • Offshore platforms.
• Food Industry:
  • Food processing equipment
  • Hygienic environments.

Mounting Plates And Brackets In Galvanised Steel

Brand: EHT Mühendislik

Category: ACCESSORIES AND INSTALLATION PRODUCTS

Each mounting bracket requires a mounting plate to fit the size of the enclosure.

Galvanizli Çelikten Montaj Plakaları ve Braketler

Application Areas:

• Filter heating
• Hopper heating
• Parabolic antenna heating
• Automotive
• Devices and systems made of metallic and non-metallic materials
• Industrial equipment mounting
• Electrical panels and distribution boxes
• Machine and equipment fixing
• Lighting system mounting
• Telecommunications equipment mounting
• Renewable energy systems mounting
• Ventilation systems.
• Construction sector.

STW II Capillary Tube Thermostat 16 A Fail-Safe

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The STW II is a compact ON/OFF type capillary tube thermostat, housed in an Ex e certified polyester enclosure.

STW II Capillary Tube Thermostat 16 A Fail-Safe

The STW II is a compact ON/OFF type capillary tube thermostat, housed in an Ex e certified polyester enclosure. Heaters, fans, motors and other equipment are energised and de-energised by means of this thermostat when specific temperature ranges are exceeded. This device can also be used to control the temperature in air or on various surfaces.

FUNCTION

Any change in temperature at the sensor bulb causes a change in the volume of fluid in the measuring system, which in turn results in a movement of the diaphragm membrane. This membrane is connected to a mechanical device that activates a microswitch. If the temperature at the sensor bulb exceeds the pre-set value, terminals 1 and 4 are opened. If there is a rupture or break in the sensor tube (leakage), then the switch remains permanently open (fail-safe). If the temperature falls below the minimum setting, the autocontrol opens the circuit but closes again on temperature rise.

APPLICATION EXAMPLE

The STW II thermostat can directly switch temperature-dependent equipment loads (heaters etc.) of up to 16 A. Higher rated currents can be switched by means of a contactor; the STW II switches the contactor coil. If an interlock is installed by means of an additional relay (according to DIN VDE 0116), the STW II can also be used as a limiter.

FEATURES

• Small construction
• Varying temperature ranges can be combined in one enclosure
• Can be mounted directly in Zone 1
• Temperature can be set in Zone 1
• Many variants available

BSTW II Safety Temperature Monitor And BTB II BSTB II Limiter 25 A Fail-Safe

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

BSTW II temperature monitors and BTB II/BSTB II temperature limiters are ON/OFF thermostats in Ex e certified polyester enclosures.

BSTW II Safety Temperature Monitor And BTB II BSTB II Limiter 25 A Fail-Safe

BSTW II temperature monitors and BTB II/BSTB II temperature limiters are ON/OFF thermostats in Ex e certified polyester enclosures. In addition to the use of conventional power cables, BSTW II and BTB II/BSTW II are approved for the direct connection of self-limiting BARTEC heating circuits in the enclosure terminals. A verification of thermal safety and a further approval by any third party authority is not necessary. The benefit to the customer is obvious. Any directly connected self-limiting heating circuit considerably reduces the number of junction boxes and installation cost. BSTW II and BTB II/BSTB II monitor ambient temperatures as well as different surface temperatures. In accordance with EN 60079-30-1, BTB II and BSTB II fail-safe temperature limiters are designed to switch off and remain switched off when the preset limit temperature is reached. The restart lockout requires manual resetting directly at the device.

Application Areas:

• Industrial furnaces
• Heating systems
• Plastic processing machines
• Food processing equipment
• Chemical processes
• Laboratory equipment
• Power plants
• HVAC systems
• Extruder Heating
• Hot press applications.

FUNCTION

Any change in temperature in the sensor causes a change in the volume in the liquid-filled measuring system, which in turn results in a movement of the diaphragm membrane, which is connected to a transmission mechanism, and this opens a microswitch. If the sensor temperature exceeds the set value, the contacts 1 and 2 remain continuously open. The contacts in the BTB II/BSTB II remain continuously open until there is a manual intervention.

FEATURES

• Direct connection of self-limiting heating tapes by means of BARTEC’s cold-applied technology reduces wiring and materials
• Switching voltage up to 400 V and 2 M20 x 1.5 boreholes as standard for an enhanced operation of EKL heating circuits
• Safety cut-out temperature -45 °C or -55 °C for reliable operation, even in very cold conditions
• Minimum operating temperature -55 °C for all standard variants for use all over the world without restrictions
• Wide regulating range from -20 °C to +500 °C, depending on the switch insert

BSTW II

Fail-safe safety temperature monitor.

• Falling calibration to maintain the temperature during the process
• Turns on and off automatically whenever the temperature exceeds or drops below the setpoint value

BTB II

Fail-safe temperature limiter.

• Rising calibration to limit temperature during the process
• Switches off and remains switched off once the limit temperatures are reached

BSTB II

Fail-safe safety temperature limiter.

• The BSTB II functions in the same manner as the BTB II temperature limiter, whereby the setting range is limited here to 0 °C to 130 °C or 130 °C to 190 °C based on the temperature classes T3 and T4.

DTW DTB Flame Proof Temperature Monitor Limiter

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

A change in temperature in the sensor causes a change in volume in the fluid filled in the measuring system, which in turn results in a movement of a membrane, which is connected to transmission mechanics and activates a microswitch. If the sensor temperature exceeds the pre-set level, the contact is actuated.

DTW DTB Flame Proof Temperature Monitor Limiter

The flame-proof encapsulated temperature controllers/limiters (DTW/DTB) are designed for (trace)-heating applications in the Ex area. They can be used both for protection against frost and for maintenance temperature applications. Heating units and other operating equipment are switched on and off by means of the temperature controller when the temperature is too high or too low. The DTB temperature limiter is designed with resetting lockout; resetting (restarting) is only possible on the device. Can be used for monitoring temperature in the air or on surfaces.

FUNCTIONS

A change in temperature in the sensor causes a change in volume in the fluid filled in the measuring system, which in turn results in a movement of a membrane, which is connected to transmission mechanics and activates a microswitch. If the sensor temperature exceeds the pre-set level, the contact is actuated. The temperature limiter switches off permanently if the temperature is exceeded. Once the temperature drops, the temperature limiter can be unlocked manually. If there is a break in the measuring system (leakage), the circuit remains open permanently.

APPLICATİON EXAMPLE

DTW and DTB switch temperature-dependent equipment (heating units) of up to 22/16 A directly. Higher switching currents or 3-phase applications are switched by means of a contactor.

• 22 A switching capacity
• Flame-proof enclosure
• ATEX, UL, CSA, FM Approval

Application Areas:

• Oil and Gas Refineries: Temperature monitoring of pipelines and equipment in environments with high temperatures and explosive gases.
• Chemical Industry: Temperature monitoring of reactors and storage tanks for controlling hazardous chemical reactions and preventing overheating.
• Paint and Varnish Production Facilities: Temperature control of ovens and drying chambers in production processes using flammable solvents.
• Flour and Grain Silos: Early detection of temperature increases in storage silos to prevent dust explosion risks.
• Mining: Monitoring the overheating of electrical equipment and conveyor belts in underground mines.
• Power Plants: Continuous temperature monitoring of high-temperature operating equipment such as turbines and boilers.

MTE Mini Thermostat

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

This Mini-thermostat is used to monitor the ambient temperature of heating systems as well as for the control of internal temperatures inside protective transmitter boxes or control and switchgear cabinets.

MTE Mini Termostat

• Compact design
• High switching capacity
• Extremely adaptable to the surrounding conditions
• Protection class IP 65/66

This Mini-thermostat is used to monitor the ambient temperature of heating systems as well as for the control of internal temperatures inside protective transmitter boxes or control and switchgear cabinets. In addition, it can be used for the control (signalling) of too low or too high a temperature or as an alarm contact.

STRUCTURE

A temperature sensor is encapsulated in an explosion-proof metal tube. The standard version features an external M20 thread. You can choose either a version with a cast rubber cord or one that is directly mounted to an Ex terminal box. A special version is also available with a flange fixing.

Application Areas:

• Small ovens
• Laboratory equipment
• Heating and cooling systems
• Food processing equipment
• Plastic processing machines
• 3D printers
• Incubators
• Extruder Heating
• Hot press applications.

KTE-m Cable Thermostat

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The extremely compact BARTEC bimetallic thermostat integrated in a cable is mostly used in hazardous (potentially explosive) areas for applications in which devices are to be protected against frost.

KTE-m Cable Thermostat

• Very small construction
• ATEX gas and dust approval
• High switching current
• Wide operating temperature range
• Ready for connection, maintenance-free

The extremely compact BARTEC bimetallic thermostat integrated in a cable is mostly used in hazardous (potentially explosive) areas for applications in which devices are to be protected against frost. This thermostat can be used to regulate internal temperatures of switch and control cabinets, transmitter protection boxes, measuring equipment etc.. It can also be used to monitor (indicate) excessively high or low temperatures or also as an alarm contact. The application assures the greatest possible reliability because of the conformance to the required minimum temperatures

Application Areas:

• Freeze protection of pipelines and tanks
• Control of heating cables
• Cold room heating
• Floor heating
• Industrial process heating
• HVAC systems
• Extruder Heating
• Hot press applications.

STRUCTURE

The thermostat is built into a casting element and can be mounted either over the borehole in the mounting sheet or suspended freely in the air.

FUNCTION

The ambient temperature is measured through the surface of the thermostat. The integrated, explosion-proof bimetallic thermostat switches the connected heating in accordance with this ambient temperature.

KTE-d Cable Thermostat

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The compact BARTEC bimetallic thermostat integrated in a cable is mostly used in hazardous (potentially explosive) areas for applications in which devices are to be protected against frost.

KTE-d Cable Thermostat

• Very small construction
• ATEX gas and dust approval
• High switching current
• Wide operating temperature range
• Ready for connection, maintenance-free

The compact BARTEC bimetallic thermostat integrated in a cable is mostly used in hazardous (potentially explosive) areas for applications in which devices are to be protected against frost. This thermostat can be inserted both for the outside temperature monitoring and for the regulation of interior temperatures of switch and control cabinets, transmitter protection boxes, measuring equipment etc. It can also be used to monitor (indicate) excessively high or low temperatures or also as an alarm contact. The application assures the greatest possible reliability because of the conformance to the required minimum temperatures

Application Areas:

• Freeze protection of pipelines and tanks (dual circuit control)
• Control of heating cables (dual circuit control)
• Cold room heating (dual circuit control)
• Floor heating (dual circuit control)
• Industrial process heating (dual circuit control)
• HVAC systems (dual circuit control)
• Extruder Heating (dual circuit control)
• Hot press applications (dual circuit control)
• Redundant heating systems (dual circuit control)

STRUCTURE

The thermostat is built into an aluminum body. The thermostat can be installed either over the mounting hole with M6 thread or with the M20 connecting thread.

FUNCTION

The ambient temperature is measured through the surface of the thermostat. The integrated, explosion-proof bimetallic thermostat switches the connected heating in accordance with this ambient temperature

Mini-Thermostat Bimetall Temperature Switch

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

This mini-thermostat is used both for monitoring the temperature outside the heating systems and also for regulating the temperature inside transmitter protection boxes or switch and control cabinets. It can also be used for monitoring (indicating) temperatures that are too high or too low and it can serve as an alarm contact.

Mini-Thermostat Bimetall Temperature Switch

• Very small construction
• Frost-protection

This mini-thermostat is used both for monitoring the temperature outside the heating systems and also for regulating the temperature inside transmitter protection boxes or switch and control cabinets. It can also be used for monitoring (indicating) temperatures that are too high or too low and it can serve as an alarm contact.

Application Areas:

• Small ovens and heaters
• Laboratory equipment
• Food processing equipment
• Plastic processing machines
• 3D printers
• Incubators
• Refrigerators and freezers
• Coffee machines and water heaters
• Extruder Heating
• Hot press applications
• Overheating protection for motors and electronic devices
• Air conditioning systems
• Ventilation systems

KRM Capillary Tube Thermostat 16 A

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The weather-proof capillary tube thermostat, KRM, is a mechanical change-over controller housed in a polyester enclosure.

KRM Capillary Tube Thermostat 16 A

• 16 A switching capacity
• Compact enclosure
• Double units are standard

The weather-proof capillary tube thermostat, KRM, is a mechanical change-over controller housed in a polyester enclosure. Heaters, fans, motors and other equipment are energised and de-energised when temperatures fall below or rise above certain limits. It can also be used to control the temperature in air, liquids and on various surfaces.

FUNCTION

Any change in temperature at the sensor causes a change in the volume of fluid in the measuring system, which in turn results in a movement of the diaphragm membrane. This membrane is connected to a mechanical device that activates a microswitch. If the temperature at the sensor bulb exceeds the pre-set value, terminals 1 and 2 are opened. If the temperature falls below the minimum setting, the contacts automatically close

APPLICATION EXAMPLE

The KRM thermostat can directly switch temperature-dependent equipment loads (heaters etc.) of up to 16 A. Higher switching currents of 3-phase applications are switched by means of a contactor

DEPU Complete Digital Solution – Controller-Limiter-Power Setpoint

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

DEPU is ATEX-certified and approved for use in potentially explosive areas.

DEPU Complete Digital Solution – Controller-Limiter-Power Setpoint

• Complete solution for trace heating: controller, limiter and power setpoint adjustment all in one unit
• Alteration of adjusting parameters also possible in potentially explosive areas
• Current carrying capacity 25 A
• Fault-free full wave contro
• Sensor input, intrinsically safe
• Allows easy output adaptation to heating circuit changes

DEPU serves as complete solution for pipe heating and provides temperature control, limitation and power output control in one device. DEPU is ATEX-certified and approved for use in potentially explosive areas.

Application Areas:

• Industrial furnaces and dryers
• Heat treatment plants
• Plastic processing machines (extruders, injection machines)
• Food processing equipment
• Chemical processes
• Laboratory equipment
• Power plants
• HVAC systems
• Extruder Heating
• Hot press applications.

STRUCTURE

All functional units are integrated in a standard Ex e aluminium enclosure. Connection to mains is established through 6 mm² tension clamp terminals

FUNCTION

The controller is designed as a ON/OFF controller and measures the temperature through RTD sensor inputs. The limiter works as an independent system and measures the temperature at the hot spot with its own sensor. If the temperature exceeds the limit value the limiter interrupts the heating circuit permanently from mains and a fault alarm signal is given

The power output controller works in interference free full wave control mode by means of a semi-conductor relay. Two 7-segment displays guarantee good readability of the controller and limiter temperature values through the lid's w

DPC Front Digital Programmable Temperature Control Device Family

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The DPCfront temperature control device series con-sists of three standardised temperature control de-vices that are adapted to the (trace) heating applications. Having two 7-segment displays, the operator can read both set- and measured temperature

DPC Front Digital Programmable Temperature Control Device Family

• Universal power supply
• Sensor monitoring
• Can be used in conjunction with Pt100 Ex, for temperature regulation in explosion-protected heating circuits

The DPCfront temperature control device series con-sists of three standardised temperature control de-vices that are adapted to the (trace) heating applications. Having two 7-segment displays, the operator can read both set- and measured temperature at first sight. By pressing a single button, the controllers power output is displayed, allowing an evaluate of the heating circuits quality. The control devices can act as ON/OFF or PID control devices. If desired, the autotuning function will automatically determine the optimum (PID) adjusting parameters for the control path. In all models the regulation can be switched off for maintenance work by pressing a single button. On account of the widerange voltage input the devices can be used almost everywhere in the world.

Application Areas:

• Industrial furnaces and dryers
• Plastic processing machines (extruders, injection machines)
• Food processing equipment
• Chemical processes
• Laboratory equipment
• Power plants
• HVAC systems
• Extruder Heating
• Hot press applications
• Heat treatment plants
• Packaging machines
• Cooling systems
• Ceramic kilns
• Incubators
• Medical equipment

Assembly

The control device is mounted into the front panel. The compact dimensions of the front (48 x 48 mm) allow a space-saving control cabinet design. The electrical connection is set up through terminal screws on the rear

Function

Temperature alterations in the sensor are evaluated in the DPCfront and shown as temperature readings on the top LED display. If the reading falls short of or exceeds the temperature value that can be seen in the bottom LED display, the output being used will automatically switch itself on or off to set the manipulated variable to the required value. To monitor the temperature, a high & low alarm function is pre-programmed. The devices detect malfunctioning at the sensor and in the control circuit and report these as faults. Each type of alarm is signalled as a group alarm via a relay

DPC Front Standard Temperature Control Device

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

Basic control device that can be used in the factory setting as ON/OFF control device with two relay outputs for regulation and alarm signalling for normal applications. The Easy Start-up function makes this extremely user-friendly.

DPC Front Standard Temperature Control Device

• Pre-defined parameters for two-position control
• Can also be used as PID control devices
• Easy Setup

Basic control device that can be used in the factory setting as ON/OFF control device with two relay outputs for regulation and alarm signalling for normal applications. Due to the factory basic setting only the setpoint and the alarm value(s) need to be set. The Easy Start-up function makes this extremely user-friendly. As an alternative, the same device can also be used as a control device with PID control characteristics and an external semi-conductor relay.

Application Areas:

• Industrial furnaces and dryers
• Plastic processing machines (extruders, injection machines)
• Food processing equipment
• Chemical processes
• Laboratory equipment
• Power plants
• HVAC systems
• Extruder Heating
• Hot press applications
• Heat treatment plants
• Packaging machines
• Cooling systems
• Ceramic kilns
• Incubators
• Medical equipment
• Simple heating and cooling applications

DPC Front Komfort Temperature Control Device

Brand: BARTEC

Category: EX PROOF HEAT TRACING EQUIPMENT

The DPC front Komfort temperature control device is designed with extra convenient features. In the factory setting it works as a PID Control device with a logic output and a relay output. As an alternative, the same device can also be used as a ON/OFF controller.

DPC Front Komfort Temperature Control Device

• Process-value feedback by 4 to 20 mA analog output
• Logic output for SSR
• Universal measuring input
• Very good measuring accuracy

The DPC front Komfort temperature control device is designed with extra convenient features. In the factory setting it works as a PID Control device with a logic output and a relay output. As an alternative, the same device can also be used as a ON/OFF controller. For regulation the device uses a logic output for solid state relays. The relay output is used for alarm signalling. The high and low alarm function, sensor monitoring and heating circuit monitoring offer additional safety for the temperature regulation. When using the device with the factory setting, a simple setup with just a few buttons is used to start operation for the first time. It is only necessary to set the setpoint, analog output limits, low alarm, and if required, high alarm.

Application Areas:

• Residential heating systems (underfloor heating, radiators)
• Office heating and cooling systems
• Hotel rooms
• Hospitals and clinics
• Schools and educational institutions
• Greenhouse and garden heating systems
• SPA and wellness centers
• Extruder Heating
• Hot press applications.
