HEM-PTCuPFA-68991 180 °C Series Resistance Polymer Insulated Heating Cables
High Temperature Series-Resistant Heating Cables - HEM-PTCuPFA-68991 180 °C Series Resistance Polymer Insulated Heating Cables
This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in antenna, industrial, freezing areas, roofs and many other areas.
HEM-PTCuPFA-68991 180 °C Series Resistance Polymer Insulated Heating Cables
Application Areas:
- Industrial furnaces and dryers (medium temperature applications)
- High-temperature process equipment
- Chemical process lines
- Laboratory equipment
- Automotive industry (engine and exhaust systems)
- Extruder heating
- Hot press applications
- High-temperature valves and pipelines
- Oil industry applications
- Food industry (high-temperature cooking equipment)
- Packaging industry (heat sealing equipment)
- Composite material production
- High-temperature testing and measurement devices
- Defrosting applications
- Cooling systems
- Freeze protection
HEM-PTCuPFA-68991 180 °C Series Resistance Polymer Insulated Heating Cables
| SPECIFICATIONS | |
| Cable nominal resistance | 1,08 to 8000 Ohm/km |
| Nominal temperature | 180 °C |
| Allowed load | 25 W/m (depending on heat dissipation conditions) |
| Testing voltage | 3000 V |
| Nominal voltage | 300/500 V |
| Outer diameter | approx. 3.2 to 6.0 mm |
Design:
- Heating cable: 7 wire stranded or wound
- PTFE insulation
- Cu-tinned copper braid
- PFA sheath
HEM-PTCuPFA-68991 180 °C Series Resistance Polymer Insulated Heating Cables
Application Areas:
- Industrial furnaces and dryers (medium temperature applications)
- High-temperature process equipment
- Chemical process lines
- Laboratory equipment
- Automotive industry (engine and exhaust systems)
- Extruder heating
- Hot press applications
- High-temperature valves and pipelines
- Oil industry applications
- Food industry (high-temperature cooking equipment)
- Packaging industry (heat sealing equipment)
- Composite material production
- High-temperature testing and measurement devices
- Defrosting applications
- Cooling systems
- Freeze protection
