HEM-GG-60060 400 °C Series Resistance Polymer Insulated Heating Cables
High Temperature Series-Resistant Heating Cables - HEM-GG-60060 400 °C Series Resistance Polymer Insulated Heating Cables
This cable, which has PTFE insulation providing high temperature resistance and chemical resistance properties, can be easily used in industrial, freezing areas and many other areas.
HEM-GG-60060 - 400 °C High Temperature Resistant Heating Cable
Application Areas:
- Industrial furnaces (very high temperature applications)
- Heat treatment plants
- Glass and ceramics industry
- Metallurgy industry
- High temperature testing equipment
- Power plants (boilers, turbines)
- Aerospace industry (engine tests, high temperature sensors)
- Research and development laboratories
- Metal smelting plants
- Drying ovens
- Extruder Heating
- Hot press applications
HEM-GG-60060 400 °C Series Resistance Polymer Insulated Heating Cables
| SPECIFICATIONS | |
| Cable nominal resistance | 180 to 12000 Ohm/km |
| Nominal temperature | 400 °C |
| Allowed load | 120 W/m (depending on heat dissipation conditions) |
| Testing voltage | 1500 V |
| Nominal voltage | 300/500 V |
| Outer diameter | approx. 3.0 mm (High nominal resistance heating cables may have different external diameters) |
Design:
- Heating cable: wound
- Electro-glass silk
- Electro-glass silk
HEM-GG-60060 - 400 °C High Temperature Resistant Heating Cable
Application Areas:
- Industrial furnaces (very high temperature applications)
- Heat treatment plants
- Glass and ceramics industry
- Metallurgy industry
- High temperature testing equipment
- Power plants (boilers, turbines)
- Aerospace industry (engine tests, high temperature sensors)
- Research and development laboratories
- Metal smelting plants
- Drying ovens
- Extruder Heating
- Hot press applications
