ELSR-M-AF BF Up To 65°C Self Limiting Parallel Heating Tape ELSR-M-AF BF

Brand: ELTHERM Category: SELF-REGULATING HEATING CABLE

Self-Regulating Heating Cable - ELSR-M-AF BF Up To 65°C Self Limiting Parallel Heating Tape ELSR-M-AF BF

Rated 5.00 out of 5 based on 1 customer rating

It is used in heat tracing in pipes, pumps and valves, food processing industry, automotive, heating of pipe bundle cables for water analysis, heat tracing on ships.

ELSR-M-AF BF Up To 65°C Self Limiting Parallel Heating Tape ELSR-M-AF BF

Self-regulating heating cable, certified for use in structural and lighter industrial areas with ATEX certification, safely operates at temperatures of 65°C/80°C.

Self-regulating heating cables, also known as self-adjusting heating cables, automatically regulate power output, ensuring energy efficiency. Available in various models to suit different applications and needs, these cables provide a reliable and safe heating solution.

The heating cable ELSR-M is very flexible and is used for special applications where installation dimensions are needed to be kept small. It is particularly suited for short heating circuits. This heating cable can be used for frost protection and temperature maintenance up to 65 °C.

Advantages:

Self-regulating
Two nominal outputs
Can be cut to length off the roll
Moisture proof
UV-resistant
Small dimensions

Applications:

Heat tracing on pipes, pumps and valves
Food processing industry
Automotive
Heating of tube bundle cables for water analysis
Heat tracing on vessels

Product Description

ELSR-M-AF BF Up To 65°C Self Limiting Parallel Heating Tape ELSR-M-AF BF

1) Bus wire	Nickel plated copper
2)Self-regulating heating element	Internally Regulated Heating Element
3)Insulation	Thermoplastic elastomer (TPE-O) or fluoropolymer
4) Protection	Protective braid (Cu, tin plated)
5) Outer jacket	TPE-O
6) Protective conductor connection	See 4 or Cu, tin plated with aluminium foil

TECHNICAL INFORMATION
Outer jacket	Polyethylene
Bus wire	Nickel plated copper
Maximum exposure temperature (power off)	65 °C
Maximum exposure temperature (power on)	65 °C
Nominal voltage	230 V
Bending radius, min.	25 mm
Installation temperature, min.	– 45 °C
Certificate	K-229437-13-Bs/st
DESIGN
BF	Protective braid and food-safe outer jacket, suited for use in potable water (tested by the Hygiene Institut des Ruhrgebiets [Hygienic Institute of the ‘Ruhr area’])
AF	Aluminium foil and food-safe outer jacket, for use in potable water (tested by the Hygiene Institut des Ruhrgebiets [Hygienic Institute of the ‘Ruhr area’])
