DHSU Thin-Bed Heating Mat SET

Brand: HEMSTEDT Category: FLOOR HEATING MATS

Floor Heating Mats - DHSU Thin-Bed Heating Mat SET

Rated 5.00 out of 5 based on 1 customer rating

HEM-SYSTEM® heating mats with a one-sided connection for installation in tile adhesive/or leveling compounds ideally suited to renovations of old buildings, new buildings as well as for bathrooms, showers, living rooms, offices, etc.

DHSU Thin Bed Heating Mat Set

HEM-SYSTEM® heating mats with a one-sided connection for installation in tile adhesive/or leveling compounds. Ideally suited to renovations of old buildings, new buildings as well as for bathrooms, showers, living rooms, offices, etc. The sleeveless technology also makes it especially suitable for walk-in showers.

The thin-bed heating mat set contains the following products:

HEM direct heating mat with a single connection 150 W/m² and 4.00 m connection
Temperature control with self-learning clock thermostat and sensor, UP
Sensor sleeve for the sensor pipe
Sensor pipe for the room thermostat
Switch
Assembly instruction

Applications:

Tile Floor Heating (Bathroom, Shower, Living Room, Office)
Renovation Projects Tile Heating
New Construction Tile Heating
Thin Bed Floor Heating Required Areas

Product Selection:

Quantity:

Product of your choice :

Product Description

DHSU Thin-Bed Heating Mat SET

TECHNICAL DATA
Nominal voltage	230 Volt
Output	150 W/m²
Cold connection	1 x 4.00 m
Minimum laying temperature	5 °C
Lowest bend radius	6 x dA
Resistance tolerance	-5% / +10%
Approval	VDE
Cold/warm transition	Seamless, without shrinking technology
Insulation	Fluoroplastic
Supply width	0.46 m
Calculation width	0.50 m
Protection type	IP67
Protection class	2

Heating Output (W)	Surface (m²)	Calculation Width (m)	Mat Length (m)	Order No.
150	1.00	0.50	2.00	30751-150 U-SET
225	1.50	0.50	3.00	30751-225 U-SET
300	2.00	0.50	4.00	30751-300 U-SET
375	2.50	0.50	5.00	30751-375 U-SET
450	3.00	0.50	6.00	30751-450 U-SET
525	3.50	0.50	7.00	30751-525 U-SET
600	4.00	0.50	8.00	30751-600 U-SET
675	4.50	0.50	9.00	30751-675 U-SET
750	5.00	0.50	10.00	30751-750 U-SET
900	6.00	0.50	12.00	30751-900 U-SET
1050	7.00	0.50	14.00	30751-1050 U-SET
1200	8.00	0.50	16.00	30751-1200 U-SET
1350	9.00	0.50	18.00	30751-1350 U-SET
1500	10.00	0.50	20.00	30751-1500 U-SET
1800	12.00	0.50	24.00	30751-1800 U-SET
2250	15.00	0.50	30.00	30751-2250 U-SET
